B20 Series
Blancett

B20 Series

Originally developed for the secondary oil recovery market, the B20 turbine flow meter is ideal for liquid flow measurement, both on and off the oil field. The B20 meter is specifically designed for low flow capacity waterflood projects. Engineered to withstand the demands of the most rigorous flow measurement applications, the B20 meter provides dependable operation with low maintenance.

Benefits

  • Only one moving part for reduced maintenance costs
  • Superior materials of construction for high performance in aggressive environments
  • Sensor and Display matched at the factory for easy field installation
  • Job and Grand totalizers for added flexibility

Features

  • Battery or Solar power display with typical battery life is six years
  • Enclosure is rated NEMA 4X (watertight and corrosion proof) for harsh field environments

Specifications

Size
1 in.
Temperature Range
-150…250 °F
Flow Range
0.6…50 gpm
Pressure Range
Up to 5,000 PSI
Accuracy
±1 %

Additional Specifications

Application Examples

Secondary Oil Recovery
Enhanced Oil Recovery
Chemical and Polymer Flood Systems
Oil Field Water Flood

Industries
Chemical, Refining & Petrochemical
Oil & Gas
Process or Industrial
Water & Wastewater Treatment
